Garmin ECHOMAP UHD 75sv With GT56UHD-TM Transducer

Description

The sunlight-readable 7” touchscreen chartplotter features a quick-release bail mount, and the transducer bundle adds Ultra High-Definition scanning sonar and CHIRP traditional sonar.

SONAR SUPPORT

This chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope scanning sonar system, which lets you see all around your boat in real time.

VIVID COLOR PALETTES

High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.

INCLUDED TRANSDUCER

This chartplotter comes with a GT56 transducer for Garmin CHIRP traditional sonar and Ultra High-Definition ClearVü and SideVü scanning sonars. With three scanning sonar frequencies and 20% greater range for our UHD SideVü sonar, you’ll get top performance at all depths.

PRELOADED MAPPING

Experience unparalleled coverage and detail with preloaded Canada LakeVü g3 inland maps featuring integrated Navionics data. Maps cover more than 13,000 lakes with up to 1’ contours.

QUICKDRAW CONTOURS

Create personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on the Garmin Connect app.

Boat connected.

NETWORK CAPABLE

If you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, the 7” and 9” models can share information — such as sonar, user data and charts — with them.

NMEA 2000 AND NMEA 0183 NETWORKS

Connect to your compatible autopilots, digital switching, weather, Fusion-Link audio system, media, VHF, AIS, engine data, heading sensors — such as the SteadyCast sensor — and more from one screen.

ACTIVECAPTAIN APP

Built-in Wi-Fi connectivity pairs with the free all-in-one mobile app for access to the OneChart feature, smart notifications, software updates, Garmin Quickdraw™ Community data and more1.

FORCE TROLLING MOTOR COMPATIBILITY

Take control of the most powerful and efficient trolling motor available, route it to waypoints, follow tracks and more from the screen of your chartplotter.

ENGINE CONNECTIVITY

Connect this chartplotter to different kinds of engines — including select Mercury and Yamaha models — to see RPMs, fuel flow, temperature, trim and other important information at a glance. You may need additional hardware, so be sure to check with your engine manufacturer.



General
PHYSICAL DIMENSIONS	7.6″ x 5.5″ x 2.9″ (19.2 x 14.0 x 7.4 cm)
DISPLAY SIZE	6.1″ x 3.5″; 7.0″ diagonal  (15.4 x 9.1 cm; 17.8 cm diagonal)
DISPLAY RESOLUTION	1024 x 600 pixels
DISPLAY TYPE	WSVGA display
WEIGHT	2.8 lbs (1.3 kg)
WATER RATING	IPX7
MOUNTING OPTIONS	Bail , flush or flat
POLARIZED SUPPORT	Y
POWER CONSUMPTION	Max power usage at 10 Vdc: 17.6 W  Typical current draw at 12 Vdc: 1.1 A  Max current draw at 12 Vdc: 1.5 A
ANTENNA	Internal or external over NMEA 2000
TRANSMIT POWER	1 kW traditional; 1 kW CHIRP
RECEIVER	10 Hz high-sensitivity
GARMIN MARINE NETWORK™ PORTS	1

Maps & Memory
PRELOADED MAPS	BlueChart g3 (coastal maps) and LakeVü g3 (inland maps)
ACCEPTS DATA CARDS	2 microSD™ cards (back of unit)
WAYPOINTS	5,000
TRACK LOG	50,000 points; 50 saved tracks
ROUTES	100

Outdoor Recreation
TIDE TABLES	Y

Chartplotter Features
GARMIN RADAR COMPATIBLE	N
GARMIN SONAR COMPATIBLE	Yes (built-in)
GARMIN SMARTMODE COMPATIBLE (CUSTOMIZABLE MONITOR PRESETS)	Y
SUPPORTS AIS (TRACKS TARGET SHIPS POSITION)	Y
SUPPORTS DSC (DISPLAYS POSITION DATA FROM DSC-CAPABLE VHF RADIO)	Y
SUPPORTS FUSION-LINK™ COMPATIBLE RADIOS	Y
GSD™ BLACK BOX SONAR SUPPORT	Y
GCV™ BLACK BOX SONAR SUPPORT	Y
ACTIVECAPTAIN COMPATIBLE	Y
WIRELESS REMOTE COMPATIBLE	Y

Sonar Features & Specifications
DUAL-FREQUENCY (50/200 KHZ) SONAR CAPABLE	Y
DUAL-BEAM (77/200 KHZ) SONAR CAPABLE	Y
FREQUENCIES SUPPORTED	ClearVü/SideVü (260/455/800/1000/1200 kHz)
CLEARVÜ	Yes with CHIRP (built-in)
MAXIMUM DEPTH	5,000 ft at 1kW (depth capacity is dependent on water bottom type and other water conditions)
BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP)	Y
WATER TEMPERATURE LOG AND GRAPH	Y
SONAR RECORDING	Y
SONAR HISTORY REWIND	Y

Connections
NMEA 2000® COMPATIBLE	Y
TRANSDUCER PIN NUMBERS	12-pin (orange)
NMEA 0183 INPUT PORTS	1 (Differential)
NMEA 0183 OUTPUT PORTS	1 (Differential)
WIRELESS CONNECTIVITY	Y
J1939 COMPATIBLE	Y

Additional
ADDITIONAL	USB port: 1
