Description
LIVESCOPE SONAR SUPPORT
ECHOMAP Ultra 122sv supports a variety of Garmin transducers, including Panoptix all-seeing sonar transducers and the Panoptix LiveScope LVS12 scanning sonar system (sold separately).
BUILT-IN UHD SONAR
The included GT56 transducer provides Garmin CHIRP traditional sonar and Ultra High-Definition ClearVü and SideVü scanning sonars. With three scanning sonar frequencies and 20% greater range for our UHD SideVü sonar, you’ll get top performance at all depths.
VIVID COLOR PALETTES
High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.
ADD CHARTS
Experience unparalleled coverage and detail with optional BlueChart g3 coastal charts and LakeVü g3 inland maps — both with integrated Navionics data and Auto Guidance technology.
QUICKDRAW CONTOURS
Create personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Garmin Quickdraw Community on the Garmin Connect app.
NETWORK CAPABLE
If you have multiple compatible ECHOMAP Ultra 10” and 12” units or ECHOMAP Plus or UHD 7” and 9” units on your boat, you can share information — such as sonar, user data and charts — among them.
NMEA 2000 NETWORK COMPATIBILITY
Connect to your compatible autopilots, digital switching, weather, Fusion-Link audio system, media, VHF, AIS, engine data, heading sensors — such as the SteadyCast sensor — and more from one screen.
ACTIVECAPTAIN APP
Built-in Wi-Fi connectivity pairs with the free all-in-one mobile app for access to the OneChart feature, smart notifications, software updates, Garmin Quickdraw Community data and more1.
FORCE TROLLING MOTOR COMPATIBILITY
Take control of the most powerful and efficient trolling motor available, route it to waypoints, follow tracks and more from the screen of your chartplotter.
TAKE IT WITH YOU
Keep your ECHOMAP Ultra safe and secure. Cords plug directly into the quick-disconnect bail mount, which allows you to quickly install and remove your unit.
Specifications:
| Physical dimensions | 13.4″ x 9.0″ x 3.9″ (341 x 229 x 98 mm) |
| Water rating | IPX7 |
| Mounting options | Bail or flush |
| Antenna | Internal or external over NMEA 2000 |
| Receiver | 10 Hz |
| Display size | 10.3” x 6.4”; 12.1″ diagonal (26.1 cm x 16.3 cm; 30.7 cm diagonal) |
| Display resolution | 1280 x 800 pixels |
| Weight | 5.5 lbs (2.5 kg) |
| Display type | WXGA display |
| Accepts data cards | 2 microSD cards |
| Track log | 50,000 points; 50 saved tracks |
| Routes | 100 |
| Maximum depth |
2,300 ft @ 77 kHz, freshwater 1,100 ft @ 77 kHz, saltwater (depth capacity is dependent on water bottom type and other water conditions) |
| Wireless remote compatible | No |
| Dual-frequency (50/200 kHz) sonar capable | Yes |
| Transmit power | 600 W (RMS) / 4,000 W (peak to peak) |
| SiriusXM Weather & Radio compatible | No |
| Polarized Support | Yes |
| Water temperature log and graph | Yes |
| Supports FUSION-Link compatible radios | Yes |
| Power consumption | 26 W |
| NMEA 0183 output ports | 1 |
| NMEA 2000 compatible | Yes |
| Bottom lock (shows return from the bottom up) | Yes |
| CHIRP sonar technology | Yes (Built-in) |
| NMEA 0183 compatible | Yes |
| Frequencies supported |
|
| Transducer pin numbers | 1 – LVS sonar, 1 – 12 pin scanning sonar |
| Supports AIS (tracks target ships position) | Yes |
| GSD Black Box sonar support | No |
| GCV Black Box sonar support | Yes |
| Sonar history rewind | Yes |
| SideVü | Yes with CHIRP (built-in) |
| ActiveCaptain compatible | yes |
| GRID (Garmin Remote Input Device) compatible | No |
| Garmin Radar compatible | No |
| Supports DSC (displays position data from DSC-capable VHF radio) | Yes |
| Garmin Marine Network ports | 2 (large connector) |
| Garmin Sonar compatible | Yes |
| NMEA 0183 input ports | 1 |
| Wireless connectivity | Yes |
| Wireless mouse compatible | No |
| Sonar recording | Yes |
| Dual-beam (77/200 kHz) sonar capable | Yes |
| Waypoints | 5,000 |
| Garmin SmartMode compatible (customizable monitor presets) | No |
| Garmin Meteor Audio System compatible | No |
| ClearVü | Yes with CHIRP (built-in) |
| Sailing Features | Yes |
| Tide tables | Yes |
